Barn House Double
Atrium Series$ 1000,00
- Usable area:179,85 m²
- Garage area:+39,76 m²
- Development area:277,03 m²
- Height of the building at the ridge:5,85 m
- Roof pitch:35°
Choose a package type:
The project price includes:
PROJECTS OPTIMIZED FOR CONSTRUCTION AND ENERGY EFFICIENCY
750 $0 $
PROJECT ADAPTED FOR AIR SOURCE HEAT PUMP AND UNDERFLOOR HEATING
750 $0 $
PROJECT WITH MECHANICAL VENTILATION AND HEAT RECOVERY
HOUSE PLANS:
GROUND FLOOR 219,61 m²
SCHEMATIC SECTIONS:
FUNCTIONAL LAYOUT:
The building features a simple, clear functional layout. The functional layout is based on two barn-like volumes connected by a communication link. These volumes serve separate functional zones: private bedroom, living area, and the connecting link. The link, serving as the entryway, contains a convenient, well-lit vestibule connected to a spacious wardrobe, a technical room, and a two-car garage. Upon entering the building, there is a visual opening to the internal patio. The garage includes a niche that creates additional storage space. In the living area, there is an open kitchen with a large island and a pantry, which is directly connected to the garage. Thanks to large glazing and the full height opening, the dining and living areas are spacious and bright. The living room opens up visually to the plot on three sides and is directly connected to the terrace. Between the two barn volumes, an internal patio is designed, connected to an intimate, private terrace with a visual opening to the plot. The terrace has a roof overhead. The bedroom zone is appropriately distanced from the public, daytime part of the house to give it a private character. This section contains three rooms, a bathroom, a laundry room, and a master bedroom with its own bathroom and wardrobe. The internal terrace between the buildings is accessible from both the living room and the main bedroom. Additionally, the space above the kitchen can be adapted into a small mezzanine by changing the ceiling to a concrete one.
One house, two barns. Could it get any better?
This proposal features a modern, single-story building with two barn-like volumes connected by a link. This design creates a pleasant, private patio at the back for relaxation. One of the volumes contains a garage with a storage room and the living area – a kitchen with a pantry, a dining table, and a lounge area. The link houses the main entrance to the house, a vestibule with a wardrobe, and a toilet. The other barn-like volume is the bedroom section. Three bedrooms share a bathroom with a bathtub. One of the bedrooms is a master bedroom with its own wardrobe and bathroom. Between the two barn-like volumes, there is a semi-atrium with a covered terrace.
BUILDING STANDARD AND CONSTRUCTION TECHNOLOGY
The building is designed to energy-efficient standards in compliance with the Technical Conditions from 2021 – featuring underfloor heating via an air-source heat pump and mechanical ventilation with heat recovery.
WALLS:
- Masonry, two-layer – aerated concrete blocks + polystyrene, internal walls made of silicate
FACADE:
- Silicone plaster, clinker tiles + wooden boards
CEILING:
- Wooden, including the roof truss (possible prefabrication)
STAIRS:
- None (possibility to install system stairs or a hatch to the non-usable attic)
ROOF:
- Flat concrete or ceramic tiles
Additionally, the simple, gable roof allows for the installation of photovoltaic panels on the southern and western slopes. The visualizations show 21 panels generating approximately 8 kW of power.
BUILDING STRUCTURE:
A simple single-story house consisting of two modern barns covered with symmetrical gable roofs with a pitch angle of 35 degrees. The two main volumes are connected by a link covered with a flat roof. The building is characterized by a uniform and minimalist style. There is a possibility of designing a terrace on the link’s roof or a gable roof in case of zoning or planning requirements.
An advantage is the patio separated between the buildings and an intimate terrace open to the plot, this space seems to blend into the interior thanks to numerous glazings.
A characteristic element, contrasting with the subdued orthogonal form, is a large triangular glazing covered with a roof on the rear gable wall. The glazing illuminates the open space of the living room. The extended roof limits the penetration of sunlight and creates partial roofing over the terrace.
The building has a simple structural layout based on external load-bearing walls, small spans, and gable roofs. The roof structure is based on roof trusses and traditional trusses in the open part of the living room. This makes the house easy and economical to build.
The facade of the building is finished with white silicone plaster and contrasting dark clinker tile, with wooden cladding in accent zones. There is a possibility of adapting materials to match the local context or the investor’s individual preferences.
The basic design is tailored to rectangular plots, with a view from the rear gable wall.
MINIMUM PLOT DIMENSIONS:
The building fits plots with an entrance from either side, but it is most advantageous to locate the entrance from the north or west.
The drawing shows the minimum distances from the property boundary according to Polish building regulations. In your region, these distances may be different
However, it is possible to request a change in technology.
If you are interested in changing technology – contact us by e-mail.
FRAME BARN HOUSE
We have the ability to easily change the construction of the house to either steel or wood frame technology.
Benefits of frame technology:
- wooden frameworks are more resistant to shocks and seismic forces than traditional masonry structures
- a more environmentally friendly solution
- shorter construction time, shorter working hours for workers
PREFABRICATED BARN HOUSE
Barn Houses Ideas collaborate with a company that specializes in manufacturing building components, like: ceilings, walls, roof, etc.- in factories and then transporting and assembling them on site.
The technology allows for a construction time reduction by half. You are able to build your barn house in 4-5 months.
Prefabricated construction is about 15-25% more expensive than comprehensive traditional construction.
What do you gain in return? Among other things:
- an ecological house made of natural materials
- quick realization of the house even in 4-5 months, and thus also immunity to unstable prices on the market
- minimal involvement in the construction – without the restriction of teams and materi
greater usable area of the building due to the smaller thickness of the walls - a house situated on a foundation slab
- guidance and advice from an experienced team
- noticeably better quality and durability of individual components.
MODULAR BARN HOUSE
If you have any additional questions or you need advice – contact us
ADD-ONS TO THE PROJECT
During the ordering process (after adding to the cart), you can choose from a variety of add-ons for the project:
Files in .dwg
- Cost $380
Project drawings in editable .dwg format.
Additional visualizations
- Cost $250
If you are considering a different material for the facade, you can order an alternative version of visualizations according to your needs. This includes 2 views – 1 from the front and 1 from the garden – with different materials in .jpg format. This service applies only to standard projects without modifications. Delivery time is up to 2.5 weeks.
In the Comments field describe the materials you would like to see in your version of the facade.
3d model in .skp
- Cost $380
Building model in editable .skp format with basic furnishings. Helpful for interior design
Custom add-ons
If you have specific requirements please contact us
Package type
Basic Package
This is the basic information used to familiarize yourself with the project and determine if it is suitable for your plot. This package is not sufficient to build a house.
The package consists of:
- Basic drawings of:
- building plans
- building sections
- Roof plan
- Elevations with description of the materials
- The most important project information
- Architectural visualisation
- Joinery schedule
Files in PDF format
If you purchase the Basic Package, you will receive a 25% discount on the Full Package, valid for 2 weeks.Full Package
This is a complete project documentation - it contains all the trade drawings needed to build our house.
The package consists of:
Basic Package(detailed drawings)+
- Drawings & Description of:
- Construction
- Sanitary Instalation
- Electrical Instalion
- Technical description of the building
Files in editable format:
- Layouts in .dwg
- 3d model in .skp
| Basic Package | Full Package | |||
| Floor plans | x | x | ||
| Sections | x | x | ||
| Elevations | x | x | ||
| Elevation Materials Schedule | x | x | ||
| Partition Types | x | x | ||
| Windows Schedule | x | x | ||
| The most important project information with basic parametrs | x | x | ||
| Roof plan | x | x | ||
| Architectural visualization | x | x | ||
| Technical description of the building | x | |||
| Sanitary Instalations - description & drawings | x | |||
| Mechanical ventilation systems plans | Plumbing plans | Central heating systems plans | x | |
| Electrical Instalations - description & drawings: | x | |||
| Plan with: switchboard, electrical sockets, lighting fixtures and switches | Electricity board scheme | Lighting protection system | x | |
| Construction description & drawings: | x | |||
| Structure plans (with reinforcement) | Foundation plan | Roof Truss Detail Plan | x | |
| Roff truss elements schedule | Reinforcing steel schedule | Construction details | x | |
| Energy performance characteristics | x | |||
| Basic layouts in .dwg | x | |||
| 3d model in .skp | x |
Plan version
Standard Plan
Mirrored Plan
Plots have different shapes and entrances from different sides. To make it easier for you to adapt our warehouse plan to your plot of land, we offer you a choice between two versions of the warehouse plan: the standard plan and the mirror plan.
The most important factor in choosing between the two is the direction of the world from which the entrance is located. This determines which version of the plan will fit the most for your plot.
In the ‘Plot’ section of the product page, we provide a detailed description of our recommended entrance location. Take a look at this information and choose the variant that best suits your plot.
In addition to the option to change the building technology and construction, described in the “Construction Options” tab for each project, it is also possible to introduce additional modifications. We handle both minor changes and more advanced ones, such as modifing the layout of rooms in the house or changing the appearance of the facade.
If you are interested or have any questions regarding this, please contact us.
Describe in an email the modifications you are interested in, and we will price them individually.
